EICHER • CONSTRUCTION TIPPER
Pro 6025T 250 HP
Discover Eicher Pro 6025T 250 HP at Thompson Motors. Explore the vehicle, read the details and plan your next move.
Construction tipper
Make it your next move.
- 25-tonne nominal GVM
- 7.7-litre VEDX8 engine
- 250 hp
- 950 Nm
Equipment and specifications depend on the selected version. Our team will confirm the details for your quotation.
A CLOSER LOOK
Explore Pro 6025T 250 HP.
DESIGNED FOR YOUR JOURNEY
Get to know your vehicle.
Overview
The 250 hp version of the Pro 6025T construction tipper uses a 7.7-litre VEDX8 common-rail engine with 950 Nm. This is a separate specification from the 280 hp model.
Applications
Body and operating applications listed by Eicher include ready mixer, light construction. Body fitment and availability are confirmed with your quote.
Configuration and availability
Specifications shown are from the official South African catalogue. Vehicle and body configuration, lead times and current availability are confirmed by Thompson Motors.
THE DETAILS THAT MATTER
Specifications.
| GVM | 25700 |
|---|---|
| FAW (laden) | 7700 |
| RAW (laden) | 18000 |
| Tier Mass – w/o load body | 8050 |
| Model | VEDX8, 6 Cylinder 4 Valve per cylinder, turbo charged, intercooled diesel, common rail |
| Capacity | 7700 cc |
| Max Power | 250 Hp @ 2200 rpm |
| Max Torque | 950 Nm @ 1100-1850 rpm |
| Emission | Euro III |
| Gear Box | ZF 1110TD (9 Forward 1 Reverse) |
| Gear Shift Linkage | Single Rod GSL |
| Clutch | 430 mm Plate Dia, spring loaded pull type with clutch booster |
| Rear Axle Ratio | 5.286 |
| Type | Ladder type joggle frame |
| Section | 285 X 76 X 7 |
| Type | Power steering |
| TCD (M) | 14.5 |
| Front Suspension | Parabolic leaf springs with hydraulic type double acting telescopic front shock absorber |
| Rear Suspension | Bogie suspension |
| Tyre Size | Tubeless radial 315/80R22.5-16PR |
| Wheel Rim size | 9X22.5 |
| Model | New Pro 6025T HVAC CAB with IDIS |
| Brake type | Dual Circuit, Full Air |
| Parking brake type | Pneumatic Control, hand operated (Inbuilt with Rear Spring Brake Actuator) |
| ABS | Standard |
| Battery | 24V,150AH |
| Size | 220 litres |
| Max Speed (kmph) | 86 |
| Gradeability | 49% |
| Wheel Base | 4000 |
| FOH | 1420 |
| ROH | 815 |
| Cabin Width | 2300 |
| Ground Clearance | 256 |
Specifications reflect the stated South African model or range. Equipment can vary by derivative and application; confirm your selected configuration with Thompson Motors.
